Typical applications 　　The MRU H is specially designed for motion measurements in marine applications requiring highly accurate heave measurements in environments with extreme horizontal accelerations. This MRU is an ideal sensor for roll, pitch and heave compensation of offshore cranes and echo sounders. The MRU H can also be used for typical ship motion monitoring applications such as helideck motion monitoring, hydroacoustic positioning systems, as well as hull stress monitoring. 　　Function 　　The MRU H incorporates three highly accurate accelerometers and three Micro-Electro-MechanicalStructures (MEMS) angular rate gyros. This unit achieves high reliability by using solid state sensors with no rotational or mechanical wear-out parts. 　　The unit is delivered with Windows based configuration and data presentation software. In this software vector arms from where the MRU is mounted to center of gravity (CG) and two individually configurable monitoring points (MPs), can be defined. The heave measurements can be output in four different locations (the MRU itself, CG, MP1 and MP2) simultaneously on serial lines or Ethernet port. Typical monitoring point is the transducer head or the crane tip.

Use as directed Servo amplifiers are safety components that are built into electrical plant or machines, and can only be operated as integral components of such plant or machines. The manufacturer of the machine must generate a risk assessment for the machine, and take appropriate measures to ensure that unforeseen movements cannot cause injury or damage to any person or property. If the servo amplifiers are used in residential areas, in business/commercial areas, or in small industrial operations, then additional filter measures must be implemented by the user.

This spare part has multifunctional capabilities. QuickPanel+provides core functions to help users run the world in today's interconnected environment. It is an integrated OI: an OI/HMI, a PLC/process controller, machine gateway, and data historian. This combination makes more data within reach, providing immediate insights and control, while reducing inventory and TCO. Remote programming technology makes it easy for accessing users to access accounts through a single access point. Moreover, an object-oriented programming environment means fast and easy implementation

　　Large hollow shaft with flange mounting 　　FHA-C Series Hollow Shaft Servo Actuators combine a synchronous servo motor, CSD Series Component Set, feedback sensor 　　and a specially developed output bearing. 　　Available in four sizes with gear ratios of 50, 100 and 160:1, the actuators can provide maximum torques from 39 to 823 Nm. 　　The output bearing with high tilting capacity often allows direct attachment of heavy payloads without the need for further 　　support, thereby providing simple and space saving design installations. 　　To adapt to your specific application, the FHA-C Series offers many possible combinations when selecting the motor winding, 　　motor feedback, brake, various sensors and cable as well as connector options. 　　The integrated hollow shaft can be used to feed through supply lines or services for additional axes, enabling space saving 　　designs with minimal installation dimensions required. The accurate positioning of the actuator ensures stable machine 　　characteristics, lower rejection rates and consistent quality. 　　By combining the FHA-C Actuators with the specially adapted YukonDrive® Servo Controllers, it is possible to provide a single 　　source supply for a pre-configured drive system tailored to suit your application. Alternatively, the flexible configuration of 　　the actuator ensures compatibility with almost any servo controller on the market.

This fifth generation MRU 5 is specially designed for high precision motion measurements in marine application and for users requiring high accuracy roll, pitch and heave measurements.
